PM5052-T-ETH

 Loading Images..
  1. Products
  2. PLC Automation
  3. Programmable Logic Controllers PLCs
  4. AC500-eCo
  5. CPUs
- Show Less..
No label translation
General Information
Extended Product Type:
PM5052-T-ETH
Product ID:
1SAP124000R0072
ABB Type Designation:
PM5052-T-ETH
EAN:
4013614551710
Catalog Description:
Processor module. Memory 4MB. 12 DI 24 VDC. 8DO 24 VDC 0.5A. 2 DC 24 VDC. Ethernet interface. 3 option slots (PM5052-T-ETH)
Long Description:
PM5052-T-ETH: AC500-eCo Processor module. Memory 4MB. 12 DI 24 VDC. 8DO 24 VDC 0.5A. 2 DC 24 VDC. Ethernet interface. 3 option slots. (CLASSIC) - Replaced by 1SAP124000R0172
  • Details
  • Downloads
  • Related Links
Go to section:
Navigate:
  • Back to top
  • Back to search results
Supplier Information - CNIAB
Configuration Only:
No
Country or Territory of Origin:
China
Lead Time:
33 day
Made To Order:
No
Product Sales Status:
Active
Quote Only:
No
Stocked At Warehouses:
CSB
Warranty Return:
Product under warranty must be returned
Supplier Information - CNIAB001
Country or Territory of Origin:
China
Lead Time:
0 day
Made To Order:
No
Product Sales Status:
Active
Quote Only:
No
Stocked At Warehouses:
CNIAB001EXPU
Supplier Information - DEAPR
Country or Territory of Origin:
Germany
Lead Time:
14 day
Made To Order:
No
Product Sales Status:
Obsolete
Quote Only:
No
Stocked At Warehouses:
CSE
Warranty Return:
Product under warranty must be returned
Supplier Information - INABB007
Maximum Order Quantity:
0 piece
Maximum Order Quantity:
0 piece
Maximum Order Quantity:
0 piece
Maximum Order Quantity:
0 piece
Supplier Information - USABB251
Country or Territory of Origin:
Germany
Lead Time:
14 day
Made To Order:
No
Product Sales Status:
Inactive
Quote Only:
No
Warranty Return:
Product under warranty must be returned
Additional Information
ABB Type Designation:
PM5052-T-ETH
CN8:
85371091
Controller Processing Time:
0.00002 ms
Country or Territory of Origin:
China

Germany

India
Customs Tariff Number:
85371091
Declaration of Conformity - CE:
3ADR980147
Degree of Protection:
IP20
EAN:
4013614551710
ETIM 10:
EC000236 - PLC CPU-module
ETIM 7:
EC000236 - PLC CPU-module
ETIM 8:
EC000236 - PLC CPU-module
ETIM 9:
EC000236 - PLC CPU-module
Function:
Memory 4MB. 12 DI 24 VDC. 8DO 24 VDC 0.5A. 2 DC 24 VDC. Ethernet interface. 3 option slots
Gross Weight:
0.299 kg
Input Voltage Type:
DC
Invoice Description:
Processor module. Memory 4MB. 12 DI 24 VDC. 8DO 24 VDC 0.5A. 2 DC 24 VDC. Ethernet interface. 3 option slots (PM5052-T-ETH)
Made To Order:
No
Maximum Order Quantity:
0 piece
Memory Size:
7032 kB
Memory Type User Data:
RAM
Minimum Order Quantity:
1 piece
Model Number:
Compact
Module Function:
Processor module
Number of Digital Configurable I/Os:
2
Number of Digital Inputs:
12
Number of Digital Outputs:
8
Number of Hardware Interfaces:
Industrial Ethernet 1

Other 0

Parallel 0

RS-232 0

RS-422 0

RS-485 0

Serial TTY 0

USB 0

Wireless 0
Order Multiple:
1 piece
Package Level 1 Depth / Length:
100 mm
Package Level 1 EAN:
4013614551710
Package Level 1 Height:
95 mm
Package Level 1 Units:
1 carton
Package Level 1 Width:
175 mm
Product Main Type:
PM5052
Product Name:
Distributed Automation PLCs
Product Net Depth / Length:
74 mm
Product Net Height:
135 mm
Product Net Weight:
0.257 kg
Product Net Width:
82 mm
Product Type:
PLC-AC500-eCo
Quote Only:
No
REACH Date:
20241206
REACH Declaration:
3ADR980139
REACH Information:
True - contains substances > 0.1 mass percentage
Rated Voltage (Ur):
24 V DC
Replacement Product ID (NEW):
1SAP124000R0172
RoHS Date:
2021
RoHS Declaration:
3ADR980147
RoHS Information:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
SCIP:
7d8f1700-ec04-40de-a990-f3378a32b09f Germany
Selling Unit of Measure:
piece
Short Description:
PM5052-T-ETH: Processor module
Stocked At (Warehouses):
Menden, Germany

Beijing, China

Beijing, China

Bairro Santo Antonio, Brazil

Bangalore, India
Supply Voltage:
20.4 … 28.8 V DC
UNSPSC:
32151705
WEEE B2C / B2B:
Business To Business
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
eClass:
27-24-22-07
